Anthony Jeanjean Concorde Frame- Black (Pre Order)

The Anthony Jeanjean signature 'Concorde' frame is here to pre-order and we only have 6 left available on the website.

SHIPS IN SEPTEMBER!

Specification:

Tubing: Full Multi Butted Japanese Sanko 4130 Chromoly

Head Tube Angle: 75.7º

Standover Height: 7.5” (centre of BB to centre of TT)

Rear End Length: 12.5” - 12.8”

Top Tube: 32mmø Multi butted internal gusseted

Down tube: 34.9mm taper to 32mm internally gusseted

Chain stays: Tapered 21mm-17mm (Ovalised for dent resistance)

Seat stays: Tapered 19mm-14mm

Tyre clearance: 2.2” with wheel slammed (recommended tyre is Killabee 2.1”) 2.3" Killabee tyre will fit with the wheel further back in the dropout

Sprocket clearance: 28t max (with a straight and correctly spaced sprocket)

BB Height: 11.55”

Headtube: Integrated and heat treated, drilled for gyro tabs 120mm length

Dropouts: 6mm thick heat treated with integrated chain adjusters and CNC cutouts

Included: Seat clamp bolt & chain adjusters

Sizes: 19.9”, 20.4”, 20.8” top tube lengths

Colours: Black ED/ OLY Bronze/ Chrome Plate

Weight: TBC

Warranty: 1 Year
